Scientists have developed conductive tracks that can be bent and stretched up to four times their original length, and could be used in artificial skin, connected clothing and on-body sensors.
Conductive tracks are usually hard printed on a board, but those developed by researchers at Ecole Polytechnique Federale de Lausanne (EPFL) in Switzerland are almost as flexible as rubber and can be stretched up to four times their original length and in all directions.
They can be stretched a million times without cracking or interrupting their conductivity, researchers said. Both solid and flexible, this new metallic and partially liquid film offers a wide range of possible applications. It could be used to make circuits that can be twisted and stretched - ideal for artificial skin on prosthetics or robotic machines.
It could also be integrated into fabric and used in connected clothing. And because it follows the shape and movements of the human body, it could be used for sensors designed to monitor particular biological functions.
“We can come up with all sorts of uses, in forms that are complex, moving or that change over time,” said Hadrien Michaud, a PhD student at the Laboratory for Soft Bioelectronic Interfaces (LSBI) and one of the study authors.
Extensive research has gone into developing an elastic electronic circuit. It is a real challenge, as the components traditionally used to make circuits are rigid. Applying liquid metal to a thin film in polymer supports with elastic properties naturally seems like a promising approach.
Owing to the high surface tension of some of these liquid metals, experiments conducted so far have only produced relatively thick structures.
“Using the deposition and structuring methods that we developed, it’s possible to make tracks that are very narrow - several hundredths of a nanometre thick - and very reliable,” said Stephanie Lacour, who runs the lab.
Apart from their unique fabrication technique, the researchers’ secret lies in the choice of ingredients, an alloy of gold and gallium.
“Not only does gallium possess good electrical properties, but it also has a low melting point, around 30 degrees,” said Arthur Hirsch, a PhD student at LSBI and co-author of the study.
“So it melts in your hand, and, thanks to the process known as supercooling, it remains liquid at room temperature, even lower,” said Hirsch.
The layer of gold ensures the gallium remains homogeneous, preventing it from separating into droplets when it comes into contact with the polymer, which would ruin its conductivity. The research was published in the journal Advanced Materials.
