How Indian-origin scientist and team developed the flexible sheet camera?

The Speciality Of The Flexible Sheet Camera Is That It Can Be Wrapped Around Objects To Take Pictures That Cannot Be Clicked Using Conventional Cameras.

PTI | Updated on: 15 Apr 2016, 12:12:21 PM
Camera lens (Representatinal picture)

New York:

Indian-origin scientist Professor Shree K Nayar from Columbia University along with other fellow researchers have developed a new flexible sheet camera. The speciality of this camera is that it can be wrapped around objects to take pictures that cannot be clicked using conventional cameras. Led by Nayar, the team designed and fabricated a flexible lens array that adapts its optical properties when the sheet camera is bent.

This optical adaptation enables the sheet camera to produce high quality images over a wide range of sheet deformations. “Cameras today capture the world from essentially a single point in space,” said Nayar. “While the camera industry has made remarkable progress in shrinking the camera to a tiny device with ever increasing imaging quality, we are exploring a radically different approach to imaging,” he said. (Also read. Top telcos' GSM mobile customers base hits 774 mm: COAI)

“We believe there are numerous applications for cameras that are large in format but very thin and highly flexible,” he added. If such an imaging system could be manufactured cheaply, like a roll of plastic or fabric, it could be wrapped around all kinds of things, from street poles to furniture, cars, and even people’s clothing, to capture wide, seamless images with unusual fields of view.

The design could also lead to cameras the size of a credit card that a photographer could simply flex to control its field of view. The new “flex-cam” requires two technologies - a flexible detector array and a thin optical system that can project a high quality image on the array. One approach would be to attach a rigid lens with fixed focal length to each detector on the flexible array. In this case, however, bending the camera would result in “gaps” between the fields of views of adjacent lenses. (Also read. You may soon be able to use your skin as touch screen)

This would cause the captured image to have missing information, or appear “aliased.” To solve this problem, the researchers developed an adaptive lens array made of elastic material that enables the focal length of each lens in the sheet camera to vary with the local curvature of the sheet in a way that mitigates aliasing in the captured images.

This inherent optical adaptation of the lens is passive, avoiding the use of complex mechanical or electrical mechanisms to independently control each lens of the array. The researchers arrived at their passively adaptive lens array by optimising its geometry and material properties. (Also read. Huawei debuts in wearable segment with Rs 22,999 smartwatch)

They fabricated their prototype lens array using silicone and demonstrated its ability to produce high image quality over a wide range of deformations of the sheet camera. “The adaptive lens array we have developed is an important step towards making the concept of flexible sheet cameras viable,” Nayar said.
